High Pole Lamp

High pole lamp is a kind of high-efficiency lighting equipment commonly used for large-area lighting. It is usually composed of high-intensity lamp pole, large lamp and lifting system. The following is a detailed introduction:

1. Basic structure

Lamp pole: The height is usually between 15 and 50 meters. It adopts conical steel pipe or polygonal steel structure. The surface is hot-dip galvanized for corrosion resistance and strong wind resistance.

Lamp: Mostly use high-power LED, high-pressure sodium lamp or metal halide lamp, with reflector to improve lighting efficiency.

Lifting system: The lamp is lifted and lowered by electric or manual winch, which is convenient for maintenance and repair.

Foundation: Pre-buried anchor bolts and concrete foundation to ensure stability.

2. Main types

Lifting high pole lamp: It can be lifted and lowered by pulley system and is easy to maintain.

Fixed high pole lamp: The structure is simple, and the lamp is fixed and cannot be lifted and lowered.

Combined high pole lamp: It combines lighting with billboards, monitoring equipment and other functions.

3. Features and advantages

Wide lighting range: A single lamp can cover thousands of square meters and is suitable for uniform lighting of large areas.

Energy saving and high efficiency: LED technology has lower energy consumption and longer life after popularization.

Wind and earthquake resistance: The design meets the requirements of wind resistance level (such as 12-level typhoon).

Intelligent control: It can be matched with time control, light control or remote management system.

4. Application scenarios

Square/Stadium: Such as airport square, football field, etc.

Port/Wharf: Lighting of large cargo loading and unloading areas.

Expressway: Toll station, service area or overpass.

Industrial area: Parking lot, warehouse periphery, etc.

5. Installation and maintenance

Installation: Professional lifting equipment is required to ensure that the foundation is horizontal and the lamp pole is vertical.

Maintenance: Regularly check the sealing of the lifting system, cables and lamps to prevent rust.

6. Key points for purchase

Height and power: Select according to the irradiation area (such as 25-meter pole with 400W LED lamp).

Anti-corrosion level: Coastal areas need to choose higher anti-corrosion standards (such as hot-dip galvanizing + spraying).

Compliance: Comply with national road lighting standards (such as CJJ 45-2015).

High pole lamps are the preferred solution for large-area lighting due to their high brightness, long life and low maintenance cost, and are especially suitable for public places that require safe and efficient lighting.
